Description

LM238WF5-SSA2 23.8″ FHD AIO LCD Screen In Cell Touch For Lenovo ThinkCenter M920Z M930Z

Model Name LM238WF5-SSA2
Screen Size 23.8 inch
Pixel Number 1920(RGB) 1080 (FHD)

Display Model Name LM238WF5-SSA2
Screen Size 23.8 inch
Screen Type LCM , a-Si TFT-LCD
Pixel Number 1920(RGB)??1080 (FHD) 92PPI
Arrangement RGB
Vertical Stripe
Active Area(mm) 527.04 ?? 296.46 (H??V)
Outline(mm) 535.2 ?? 313.16 ?? 12.26 (H??V??D)
Bezel Area(mm) – Treatment Antiglare, Hard coating (3H)Luminance 250 cd/m2 (Typ.) Contrast Ratio 1000 : 1 (Typ.) (TM) Viewing Angle 89/89/89/89 (Typ.)(CR??10) Left / Right / Up / Down Response 14 (Typ.)(G to G) msGood View at Symmetry Work Mode IPS, Normally Black, Transmissive [Panelook copyright, copy is strictly prohibited]IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, VistarichVA Family: ASV, HVA, MVA, PVA, SVA, UV2A, VAColor Depth 16.7M 72% NTSC Backlight WLED , 30K hours , No DriverMass 1.92/2.01Kgs (Typ./Max.) Used for Desktop MonitorRefresh Rate 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit120Hz+120Hz : 120Hz Panel+120Hz Backlight240Hz (60HZ Input) : Embedded MEMC Circuit Touchscreen In-Cell TouchSignal Type LVDS (2 ch, 8-bit) , 30 pins ConnectorVoltage Supply 5.0V (Typ.) Max. Ratings Storage Temp.: -20 ~ 60 ??C Operating Temp.: 0 ~ 50 ??C
